FEATURED Standard Pallet Truck

model: PM5-2748-Y


Standard Pallet Truck
SERIES: PM5   2Products 1Options
Powder Coat Quick Ship

Economy Pallet Jacks for Manual Pallet Load Transport

Economy pallet trucks provide a dependable manual material handling solution for moving heavy pallet loads without a fork truck. Designed for warehouses, stockrooms, shipping areas, retail backrooms, manufacturing plants, and distribution centers, these pallet jacks help one operator move palletized materials efficiently across facility floors.

Ergonomic Manual Handling

The proven handle design requires only 75 lb. of pulling force when fully loaded, helping support user-friendly operation during everyday pallet movement. A spring-loaded loop handle automatically returns to the vertical position when not in use, keeping the truck ready for the next move.

Reliable Hydraulic Performance

A chrome-plated hydraulic pump piston supports long seal life and low-maintenance operation. The service range handles standard pallet lifting needs, while 7 inch wide forks and 48 inch fork length provide practical compatibility with common pallet sizes.

Capacity, Finish, and Options

This family supports 5,500 lb. capacity with a 27 inch fork spacing and durable yellow powder-coated finish. Units are available individually or in crated six-pack quantities for high-volume stocking programs.

Ships with the Handle Detached Standard

Standard Pallet Truck

model: PM5-2748-Y

Model # Description Attributes Net Wt.
(lbs)

All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.

KEY: = Expand Model Details = Quickship item = Non-Returnable item = Approval Drawing Required = Non-Cancelable Item
= On Hold/Temporarily Unavailable = Approval Drawing = Testing Certificate = BABAA Compliant = 360 Image Warranty
= New Images Coming Soon! = Dimension Image = Works w/ Skid Only = Flatbed Truck Required

If you did not find an expected Model or SKU # in the table, try the Options Section Below
For More Details of the Option Click the Red Model Button
Model Image Details Icons Wt.
Model Image Description WT.
PM-FE-7-48 BOL-CAP-1.75-P Steel Pallet Master Fork Extensions 7"W x 48"L x 2"H 19
If you did not find an expected Model or SKU # in this table, try the Product Specifications Section Above
PDFs will open in a new window when clicked.

Survey Sheets

0
No survey sheets for this product family.

Approval Drawings

1

SDS Sheets

0
No SDS sheets for this product family.

Other PDFs

0
No other PDFs for this product family.
Hydraulic pump includes overload
relief valve.Pump bypasses at full
height
User friendly entry and exit rollers
with adjustable push rods






Standard Pallet Truck




Economy Pallet Jacks for Manual Pallet Load Transport

Economy pallet trucks provide a dependable manual material handling solution for moving heavy pallet loads without a fork truck. Designed for warehouses, stockrooms, shipping areas, retail backrooms, manufacturing plants, and distribution centers, these pallet jacks help one operator move palletized materials efficiently across facility floors.

Ergonomic Manual Handling

The proven handle design requires only 75 lb. of pulling force when fully loaded, helping support user-friendly operation during everyday pallet movement. A spring-loaded loop handle automatically returns to the vertical position when not in use, keeping the truck ready for the next move.

Reliable Hydraulic Performance

A chrome-plated hydraulic pump piston supports long seal life and low-maintenance operation. The service range handles standard pallet lifting needs, while 7 inch wide forks and 48 inch fork length provide practical compatibility with common pallet sizes.

Capacity, Finish, and Options

This family supports 5,500 lb. capacity with a 27 inch fork spacing and durable yellow powder-coated finish. Units are available individually or in crated six-pack quantities for high-volume stocking programs.

Ships with the Handle Detached Standard



Model # Description Attributes Net Wt.
(lbs)
PM5-2748-Y PM5-2748-YSteel Pallet Truck 61-11/16 In. x 28-3/4 In. x 48-5/8 In. 5500 Lb. Capacity YellowUniform Capacity (lb.): 5,500
Fork Spacing (in.): 27
198
PM5-2748-Y-6PKG PM5-2748-Y-6PKGSteel (Quantity 6) Pallet Truck 61-11/16 In. x 27 In. x 48-5/8 In. 5500 Lb. Capacity YellowUniform Capacity (lb.): 5,500
Fork Spacing (in.): 27
960

Options


Model Image Description WT.
PM-FE-7-48 BOL-CAP-1.75-P Steel Pallet Master Fork Extensions 7"W x 48"L x 2"H 19
